Draeger Alcotest 7510 - the best Dräger breathalyzer on the market!

The Draeger Alcotest 7510 is a compact and robust hand-held measuring device that is suitable for both right-handed and left-handed people thanks to its special ergonomic shape. A non-slip rubber sheath and the hand strap ensure safety. Depending on official and market-specific specifications, the measurement results can also be used for judicial evidence.

The Draeger Alcotest 7510 can be used immediately in any environment. It can be used at temperatures from -10 ° C to +50 ° C. The flexible data management, the high storage capacity and the possibility of wireless data transmission to the Draeger Mobile Printer or a PC make it easy to adapt the device to different national and international specifications.

The Draeger Alcotest 7510 features comprehensive data management and can capture and store a wealth of information. For example, the calibration intervals, the type of vehicle, the license plate, the name of the vehicle driver and the location and reasons for the measurement can be logged. The possibilities of configuration are almost unlimited. The test result will be saved together with these entries as well as with a unique test number and the time and date.

Product features:

- Measuring range between 0.00 to 3.0 mg / L
- very fast between 3 - 10 sec. (depending on the temperature)
- wide range of application from -10 to +50 ° C
- Measured value memory for 5,000 measured values
- Passive & active mode when taking the measurement
- 4 languages adjustable via the menu (English, German, French, Spanish)
- Electrochemical DrägerSensor in 1/4 "technology
- Graphical LCD display with backlight
- 3-color LED to support the display and warning messages
- Acoustic signal to support measurements
- Simple three-button operation
- Slide'n'click mouthpiece
- Weight: 430 g including batteries
- Connection to the Dräger Mobile Printer
- 4 AA alkaline batteries or NiMH batteries
- Calibration recommended after six to twelve months


Technical specifications:

Scope: Public & commercial areas
Measuring range: 0.00 to 2.5 mg / l via LCD display
Display: Audible and visual (lit) Full text messages via LCD display (128 x 169 pixels)
Accuracy: Accuracy: +/- 0.005% at 00:10% BAC (Blood Alcohol Concentration BAC =), equivalent to approximately +/- 5% at 1.0 per mill!
Warm-up time: max. 6 seconds
Measuring time: about 3-10 seconds
Sensor: electrochemical (Dräger Fuel Cell Sensor), 1/4 "technique
Data Logger: memory for 5,000 tests with respective test number + date and time
Weight: 430g
Size: 185mm (height) X 90mm (width) x 45mm (depth)
Material: ABS plastic, black
Certifications: CE certification, RoHs
Power supply: 4 pieces 1.5V "AA" alkaline battery for about 1,500 samplings, Auto Power Off
Data Interface: USB interface, via IR Infrarotmodul (optional)



Scope of supply:

- Breathalyser Dräger Alcotest 7510 - Standard
-4 Piece Alkaline Batteries AA
-3 Mouthpieces with orientation to the right
-Bereitschaftskoffer
-Product CD
-USB cable


Datasheets:

   Datasheet Dräger Alcotest 7510
   User manual Dräger Alcotest 7510 german/englisch


NOTE:  The manufacturer and the sellers will not take any legal responsibility for the test results.
