Healthmonitor ECG-Monitor/Recorder - ECG Recorder in your pocket

The small heart monitor belongs to a new generation of mobile ECG monitors. It is the perfect self-monitoring device for on the road or at home, as the measuring time ranges from 30 seconds to up to 5 minutes (only with external electrodes). The result (heart rate & pulse) is then automatically interpreted by the device. The wireless application and the direct display of the heart rate and waveform on the display allow a quick assessment of the cardiac condition. The device has 100 measuring stations. What we like very much is that the Healthmonitor can be easily controlled with a finger via touch screen. However, the menu navigation is in English language.

Reliable and Professional Analysis:

- Arrhythmia
- Heart Pause
- Atrial Fibricular (AF)
- Tachycardia & Bradycardia
- Premature Ventricular Contraction (PVC)

Product features:

- Take noise-free EKG with cable and reusable electro pads
- Take EKG cable free on your palm
- Wireless personal EKG monitor
- Lead I, Lead II or Chest Lead
- 30s / 60s / 5m recording duration
- Card size, built-in memory, touch screen with graphic guidance
- free App for iOS/Android (Check Mobile)
- free PC/Mac Application under Link: Pulsebit Browser Pro
- Ultra-portable for mobile use
- Rechargeable battery (USB)
- certified medical product according to MDD 93/42 / EEC

Technical Specification:

Size: 88×56×13 mm
Weight 64 g (main unit)
Display 2.4” touch screen, color, backlit
Connector Micro-USB connector
Power Supply Battery type Rechargeable lithium-polymer battery
Battery run time Daily check: > 200 times
Charge time Less than 2 hours to 90%
Record length 30s/60s/5min
Sampling 500 Hz / 16 bit Display
Gain 1.25 mm/mV, 2.5 mm/mV, 5 mm/mV /n 10 mm/mV, 20 mm/mV
Sweep speed 25 mm/s
Bandwidth 0.67 to 40Hz
Electrode offset potential tolerance ±300 mV
HR measurement range 30 to 250 bpm
Accuracy ±2 bpm or ±2%, whichever is greater /n
Standards Meet standards of ISO 80601-2-61
PR range 30 to 250 bpm
PR accuracy ±2 bpm or ±2%，whichever is greater
PI range 0.5-15
Storage 100 pcs of records

Box contents:

Further Information:
